Electrical parameters:

Voltage: 100V~240V AC, 50/60Hz

Power: 580W @ 220V

Power factor: PF>0.9

Light source specification:

Light source:400W high brightness Module LED

Color temperature:6500K-7000K

Life time:50000 hours

colour:

1 color wheel: 14 colors + white,half-color rainbow effect

2. Independent multi-color wheell

2. Linear CMY function, color can be adjusted;

Can be mixed to make the color richer.

Gobo wheel:

1. 1 fixed gobo wheel:13 gobos + white+4 beam

Prism:

2pcs prism, dual-direction rotation

Focus:

DMX linear focus adjustment, super smooth focus adjustment.

Strobe/Dimming:

Electronic strobe, 0.3-25 times/second,linear dimming

Frost:

Independent frost lens, softer light

Rotation angle:

Use three-phase stepping motor, fast, quiet, with automatic return function.

Horizontal:540°

vertical: 270°

Beam Angle:

2°

Control mode:

DMX512 signal

20/24CH channel mode

Other functions:

Horizontal and vertical speed adjustable

Use powerful silent fan, LED temperature display, reduce power due to overheating, and ensure LED lifetime

Modular structure for easy maintenance

Color screen with Chinese and English menus.

Displays DMX values for each channel.

The screen automatically rotates according to the lighting fixture's hanging direction.

Features an automatic error reporting function.

Protection level:

Protection grade: IP66

weight:

Net weight: 22.0kg

Gross weight: 26.0kg

packing size: (mm)

520(L)*350(W)*860(H)

Working temperature:

Maximum ambient temperature 50°C
